MS 160100
Artikelnummer:
Tryckmätare vertikal, 100mm, 0 - 160 bar G 1/2"
Tryckmätare vertikal, 100mm, 0 - 160 bar G 1/2"
Beskrivning
| Diameter [mm] | 100 |
| Display range [bar] | 0 - 160 |
| Scale division | 5,00 |
| Note | RoHs-compliant |
| Weight | 230 g / pc. |
| Customs duty number: | 90262040 |
Description
Materials:
Housing: black plastic, measuring system and indicator: copper alloy, window: clear plastic (Ø 160: Housing: black steel, measuring system and indicator: copper alloy, window: instrument plate glass)
Connection thread:
G 1/2"**
Class:
2.5, (Ø 160: 1.6)
Temperature range:
Environment: -20°C to max. +60°C, measured material: max. +60°C
Protection class:
IP 42
*comes with a red marking indicator, **with centring pin for profiled seal
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C
