Finns i materialvarianterna; Förnicklat stål, rostfritt 1.4305, syrafast 1.4404

Kompatibel med: Rectus (25, 26, 1600, 1625), TEMA (1600), CEJN (320), JWL (520, 530, 560), Legris (25, 26), Parker (PE, PEF), Prevost (E ... 07), Festo (KD4 / KS4), IMI-Norgren (238), Aventics (CP1-NW 7 / 7,8)

Materials:

Housing: Brass, nickel-plated brass, steel hardened, 1.4305, seal: NBR (stainless steel: FKM)

Temperature range:

-20°C to max. +100°C (stainless steel: -15°C to max. +200°C, plastic sleeve max. +80°C)

Operating pressure:

-0,95 bis 35 bar

Flow***:

Bolt lock: 1100 l/min (option -BA: 800 l/min), ball lock: 1850 l/min (option -BA: 750 l/min), ball lock/plastic sleeve: 2100 l/min

Note:

Coupling plugs with valve for double-sided shut off (-BA) can only be used with the special coupling sockets (-BA) provided for them.

Compatible with**:

Rectus (25, 26, 1600, 1625), TEMA (1600), CEJN (320), JWL (520, 530, 560), Legris (25, 26), Parker (PE, PEF), Prevost (E ... 07), Festo (KD4 / KS4), IMI-Norgren (238), Aventics (CP1-NW 7 / 7,8) und viele andere deutsche Fabrikate

Optional:

Body made from 1.4404 -ES4AKV, usable for plug shut-off on both sides -BA

***6 bar input pressure, 0,5 bar pressure difference

* Coupling can be used with plug without shut-off and with shut-off BA.

**Names and designations are partly trademarks of the manufacturers entered.
